| ブランド名: | Raymo |
|---|---|
| 証明: | CE/RoHs/REACH/ISO9001:2015 |
| Model Number: | RM-2PM Series |
| Minimum Order Quantity: | 5 |
| 価格: | 1-9.99 USD |
| Packaging Details: | CTN |
| Delivery Time: | 2-3 WEEKS |
| 支払条件: | T/T、D/A、D/P、Western Union、MoneyGram |
| Supply Ability: | 5000PCS Per Month |
| 交尾サイクル: | 500回 | 取り付けスタイル: | 穴を通して |
|---|---|---|---|
| 接触資料: | 銀/金で覆われた銅 | 電圧定格: | 250V |
| 接続方法: | スレッド接続 | 終了スタイル: | 半田 |
| シェルサイズ: | 14/18/22/24/27/30/33/36/39/42/45 | 温度: | -60〜200 |
| ハイライト: | 2PM connector solder termination,2PM connector 250V thread connection,2PM connector 5-40A solder termination |
||
The 2PM Connector is a high-performance electrical connector designed for reliable connections in demanding industrial applications. Featuring a durable aluminum alloy shell and versatile specifications, this connector delivers exceptional performance across various electrical systems.
| Attribute | Value |
|---|---|
| Mating Cycles | 500 Times |
| Mounting Style | Through Hole |
| Contact Material | Copper With Silver/Gold Plated |
| Voltage Rating | 250V |
| Connection Method | Thread Connection |
| Termination Style | Solder |
| Shell Size | 14/18/22/24/27/30/33/36/39/42/45 |
| Temperature Range | -60°C to 200°C |
| Feature | Specification |
|---|---|
| Contacts | 4/7/8/10/19/20/22/24/32/45/50 Pin |
| Material | Metal |
| Temperature Range | -60°C to 200°C |
| Connector Series | 2PM 2PX Connectors |
| Certifications | CE, RoHS, REACH, ISO9001:2015 |
The 2PM Connector is ideal for various industrial and commercial applications including:
Our comprehensive support includes:
